1. What does "pressure transmitter" mean?

Pressure transmitter English [ˈ pre ż ə tr æ nz ˈ mit ə] American [ˈ pr ɛチ rot disturbance ɚ tr æ ns ˈ m ɪ t ɚ] Dictionary: Pressure transmitter, pressure transmitter, double hungry mu dan Example 1 Design and Implementation for Low Power Consumption Wireless Pressure Transmitter Design and Implementation of Low Power Wireless Pressure Transmitter 2 A leak detection and positioning system of oil pipeline based on dynamic pressure transmitter is designed, and the system composition and testing principle are specified. A set of oil pipeline leakage detection and positioning system based on dynamic pressure transmitter was designed, and the system composition and detection principle were explained.

2. MiniLED release film

3. Request an English document on the design of an ultrasonic rangefinder based on a microcontroller (with Chinese translation attached)

This article described the three directions (before, left, right) ultrasonic ranging system is to understand the front of the robot, left and right environment to provide a movement away from the information. (Similar to GPS Positioning System) A principle of ultrasonic distance measurement 1, the principle of piezoelectric ultrasonic generator Piezoelectric ultrasonic generator is the use of piezoelectric crystal resonators to work. Ultrasonic generator, the internal structure as shown in Figure 1, it has two piezoelectric chip and a resonance plate. When it "s two plus pulse signal, the frequency equal to the intrinsic piezoelectric oscillation frequency chip, the chip will happen piezoelectric resonance, and promote the development of plate vibration resonance, ultrasound is generated. Conve

rsely, if the two are not inter-electrode voltage, when the board received ultrasonic resonance, it will be for vibration suppression of piezoelectric chip, the mechanical energy is converted to electrical signals, then it becomes the ultrasonic receiver. 2, the principle of ultrasonic distance measurement Ultrasonic transmitter in a direction to launch ultrasound, in the moment to launch the beginning of time at the same time, the spread of ultrasound in the air, obstacles on his way to return immediate ly, the ultrasonic reflected wave received by the receiver immediately stop the clock. Ultrasound in the air as the propagation velocity of 340m / s, according to the timer records the time t, we can calculate the distance between the launch distance barrier (s), that is: s = 340t / 2 Ultrasonic Ranging System for the Second Circuit Design System is characterized by single-chip microcomputer to control the use of ultrasonic transmitter and ultrasonic receiver since the launch from time to time, single-chip selection of 8751, economic-to-use, and the chip has 4K of ROM, to facilitate programming. Circuit schematic diagram shown in Figure 2. Draw only the front range of the circuit wiring diagram, left and right in front of Ranging Ranging circuits and the same circuit, it is omitted. 1,40 kHz ultrasonic pulse generated with the launch Ranging system using the ultrasonic sensor of piezoelectric ceramic sensors UCM40, its operating voltage of the pulse signal is 40kHz, which by the single-chip implementation of the following procedures to generate. puzel: mov 14h, # 12h; ultrasonic firing continued 200ms here: cpl p1.0; output 40kHz square wave nop; nop; nop; djnz 14h, here; ret Ranging in front of single
