1. Range parameters of solid dust flowmeter

The range parameters of solid dust flowmeter need to be determined according to specific working conditions and instrument types. The common range is between 0-500 kg/h and 0-200 t/h. 1. The selection of core selection parameters for dust flow meters goes far beyond the range, and the following core parameters need to be matched: • Pipeline size: DN50 to DN500 is a common range, which directly affects the upper limit of flow. Coarseness of dust special sales segment: medium name, particle size distribution, humidity, temperature, corrosiveness (such as coal powder, cement, and alumina powder with significant differences in characteristics). Process pressure: atmospheric pressure, slight negative pressure or positive pressure (such as 0.1MPa). • Expected flow range: minimum flow (Min. flow) and maximum flow (Max. flow), the range should cover this range and leave a margin

2. The main instrument types and typical ranges are different, and the instrument range and applicable scenarios for measuring the principle of loss control are different. |Instrument type | Measurement principle | Typical range (example) | Applicable scenarios | |: --- |: --- |: --- | |: --- | | | Capacitive | Utilizing the difference in dielectric constant between dust and air | 0-100 kg/h to 0-50 t/h | Powdered materials such as flour and fly ash | | Triboelectric | Detecting electrostatic signals generated by dust friction | 0-500 kg/h to 0-200 t/h | Pneumatic conveying pipelines such as cement and fly ash | | Microwave (frequency modulated continuous wave FMCW) | Transmitting microwaves to materials and analyzing echoes | 0-10 t/h to 0-500 t/h | High flow, non-contact measurement, such as

4. Important precautions - Choosing too much range can significantly reduce measurement accuracy at low flow rates. -Accurate working condition information (medium, pipe diameter, pressure, temperature) must be provided to the instrument supplier for final accounting and selection. -The installation conditions (straight pipe section requirements, grounding) have a critical impact on measurement accuracy.

2. How to measure the linearity of needle plug adjustment in solid rocket engines

The measurement method for the linearity of needle plug adjustment in solid rocket engines is as follows

1. Measurement parameters and
